Matelec FPC-36040 User Manual

13
Block
Modbus
Address
HEX Coil
Address
Modbus
Coil
Address
Register Data Coil Data
Read/
Write
Func-
tion
Codes
Description
Discrete
Coils
1
0x00 1
I/O States
Low level in
R 1,3 0=O󰀨;1=On
0x01 2 Stop in
0x02 3 Start in
0x03 4 High level in
0x04 5 Pump 1 fault in
0x05 6 Pump 2 fault in
0x06 7 Pump 1 out
0x07 8 Pump 2 out
0x08-0x0f 9-16 Unused
2
0x10 17
Alarm states
High level fault
R 1,3 0=O󰀨;1=On
0x10 18 Low level fault
0x10 19 Pump 1 fault
0x10 20 Pump 2 fault
0x10 21 Low pressure fault
0x10 22 Pump 1 prime loss
0x10 23 Pump 2 prime loss
0x10 24 Inhibit fault
0x18-0x1f 25-32 Unused
3
0x20 33
System states
Single pump mode
enabled
R 1,3 0=O󰀨;1=On
0x21 34
Current loop mode
state
0x22 35 Mute state
0x23 36 Alarm test active
0x24 37 Inhibit fault enable
0x25 38 Pump inhibited
0x26 39 Current loop invert
0x27-0x2f 40-48 Unused
Coils
4 0x30 49
System states
Set mute ag
(write only)
W 5
0=O󰀨;1=On
5 0x40 65
Reset alarms
(write only)
0=O󰀨;1=On
MODBUS COILS
