Matelec FPC-36040 User Manual

3
FRONT SIDE VIEW
Top
Bottom
Top
Bottom
Mounting
Frame/
Wall
PUMP 1 PUMP 2
AUTOAUTO
Running Idle
System OK. No Alarms
DUAL PUMP CONTROL
MAIN ISOLATOR
LOW
LEVEL
ALARM
COMMON
N/O CLOSE ON RISE
BLUE NOT REQUIRED
STOP
LEVEL
COMMON
N/O CLOSE ON RISE
BLUE NOT REQUIRED
START
LEVEL
COMMON
N/O CLOSE ON RISE
BLUE NOT REQUIRED
Input 1
Low
Level
Input 2
Stop
Level
Input 3
Start
Level
INPUT SWITCHES
T1 T2
Pump 1 Pump 2
THERMAL SWITCH
12Vdc Connections
415Vac
MAINS POWER
SUPPLY
REMOVE
BRIDGING WIRE
TO USE
LOW LEVEL
BRIDGE
IF NOT
REQUIRED
NE A1
SUPPLY
415Vac Connections
A2 A3 T1 T2
HIGH
LEVEL
N/O CLOSE ON RISE
BLUE NOT REQUIRED
Input 4
High
Level
COMMON
PUMP 2
P3P1 P2
PUMP 2
PUMP 1
PUMP 1 Earth
PUMP 2 Earth
PUMP 1
P2
P3
P1
COMMON
FAULT
BMS
VOLT/FREE
COMMON
INPUT
SHIELDED
TRANSDUCER
CABLE
HYDROSTATIC
LEVEL
TRANSDUCER
SHIELD EARTH
4-20mA
+ -
Level
Transducer
12Vdc
T1 T2
Pump 1 Pump 2
THERMAL SWITCH
415Vac
MAINS POWER
SUPPLY
Current loop
enabled to use
transducer
(see page 6)
BRIDGE
IF NOT
REQUIRED
NE A1
SUPPLY
415Vac Connections
A2 A3 T1 T2
HIGH
LEVEL
N/O CLOSE ON RISE
BLUE NOT REQUIRED
Input 4
High
Level
COMMON
12Vdc
PUMP 2
P3P1 P2
PUMP 2
PUMP 1
PUMP 1 Earth
PUMP 2 Earth
PUMP 1
P2
P3
P1
COMMON
FAULT
BMS
VOLT/FREE
INSTALLATION
MOUNTING
CONNECTION
1. Controller enclosure must be
mounted in a vertical position.
2. Ensure mounting method does not
compromise enclosure weather
proof rating.
3. Ensure access to main isolator is
not restricted.
4. Ensure cables/conduits entering
the panel have mechanical
protection and that the penetrations
are sealed and do not
compromise the weather proof
rating of the enclosure.

Matelec FPC-36040 Specifications

General

Brand	Matelec
Model	FPC-36040
Category	Controller
Language	English
