User Settings
Setting User Value Setting User Value Setting User Value
1 - System Setup
System type
Control output type
Number of pumps
Pump limit
Duty change period
2 - Analog
Level Pressure Temperature
Level analog enable Pressure analog enable
Temperature analog
enable
Max level sensor range Max level sensor range
Max temperature sensor
range
Setpoint Setpoint Setpoint
Wakeup level step Wakeup pressure drop
Wakeup temperature
step
Standby start level step
DOL Standby start
pressure step
Standby start temp step
Low level threshold Low pressure threshold
Low temperature
threshold
High level threshold High pressure threshold
High temperature
threshold
Quick Start Complete
The controller is now configured and has begun operation. For more information on the operation
of the HydroWHIZ controller, see the HydroWHIZ VSD Operation Manual.
Step 7 - Put System in Auto
On the HMI’s Main screen, change the System Mode to Auto by tapping on the toggle. The controller will now begin normal operation.
PUMP 1
RUNNING MENU
Standby Run
PUMP 2
Fault
PUMP 3
Disabled
PUMP 4
Duty Run
SYSTEM MODE:
AUTO
OFF
MANUAL
546kPa
View Faults
32.5Hz
Additional user settings on following page
