Example file stored
[DATA]
Test: [Description]
Test type: Giratory compactor test
Test date: 1/16/2013
Test time: 12:19:06 PM
Internal angle: 1.160 °
Load: 10.600 kN
Speed: 30.000 Rpm
Gyrations: 18
Mould: Ø150
Weight: 5.000 kg
Stop mode: Gyration
[RESULTS]
END TEST STOP
Gyrations: 18
Height: 117.119 mm
Density: 2415.853 kg/m³
[GRAPHINFO]
Axis0=2;1.000;18.000;0
Axis1=1;1.100;1.200;0
Axis2=1;10.200;11.000;0
Axis3=1;117.100;117.200;255
Axis4=1;2415.200;2416.100;65280
Graph1=0;3
Graph2=0;4
[GRAPH]
Gyrations Angle [°] Load [kN] Height [mm] Density
[kg/m³]
1 1.139 10.635 117.130 2415.629
2 1.134 10.604 117.115 2415.930
3 1.138 10.613 117.108 2416.077
4 1.138 10.608 117.147 2415.277
5 1.140 10.604 117.150 2415.232
6 1.139 10.617 117.149 2415.240
7 1.138 10.610 117.147 2415.283
8 1.136 10.600 117.147 2415.266
9 1.137 10.617 117.150 2415.215
10 1.137 10.609 117.147 2415.266
11 1.137 10.611 117.149 2415.240
12 1.137 10.599 117.148 2415.249
13 1.135 10.616 117.111 2416.023
14 1.136 10.614 117.116 2415.921
15 1.135 10.616 117.117 2415.887
16 1.134 10.602 117.118 2415.870
17 1.135 10.615 117.116 2415.913
18 1.133 10.594 117.119 2415.853
[CHECKSUM]
0001054D
Example of print to USB printer
