3
CHAPTER 1
THIS MANUAL IS ADDRESSED TO the carrier, the installer, the user, the maintenance operator, the
scrapping operator.
Please read it carefully because it informs you about the operating of the machine in safety conditions.
This manual has to be considered a part of the product and concerns only the machine it is delivered
with.
Keep the manual in order during the whole life of the appliance to consult it for any needs.
In case of sale, the manual and its enclosures should be given together with the machine.
The manufacturer assumes no liability for any damages caused by a misuse of the machine.
The manufacturer has the right to modify this technical literature as well as the machines this refers to
without any previous notice.
Messages meaning:
ATTENTION
This warning refers to all those procedures that have to be carefully followed to avoid
any damage to the machine.
DANGER
This warning refers to all those procedu
res that could present some risks for the
operator if not carefully followed.
MANUFACTURER IDENTIFICATION: See the cover page.
MACHINE IDENTIFICATION: See the plate on the machine where complete identification
data as well as electric features are to be found.
The laboratory Mixer E094 and E095 has been developed for the automatic mixing of the cement pastes
and mortar. This process will result in the preparation of the specimens for flexure, compression tests in
perfect compliance with the EN 196/1 specifications.
This appliance has to be used only for the aim it has been projected and manufactured for.
Any other use of the machine is not permitted.
ATTENTION
The instructions given in this operating manual are
only made for the right use of the
appliance. To carry out the test in the right way, the user must refer to the specific
standards in force for the test itself.
STRUCTURE AND OPERATING OF THE MACHINE
The appliance is mainly formed by two parts (see enclosure A for further details):
THE MIXER (B) is made by a metal sheet frame (B9/C9) and by a lower basement of aluminium; a
bowl (B14) is fixed at the bottom, while the electric disposals for the machine control as well as the
motor (B4/C4) are located at the top. A special lever (B7/C7) allows fixing the bowl to the frame. The
electric motor activates the beater (B1/C1), which mixes the mortar.
THE CONTROL PANEL (C) allows controlling the various mixer functions.
For further information please contact the Agent or the Manufacturer.
