CHAPTER 6
USE
DANGER
Consult the Chapter “DANGEROUS PARTS AND RESIDUAL RISKS” before
proceeding.
6.1
WARNING
Before proceeding with the ordinary use of the appliance, we recommend checking that the appliance is
in proper conditions to work and has no parts broken or used; eventually make all routine and special
maintenance operations listed in this manual.
ATTENTION
Nev
er start the beater rotation if the bowl isn’t at its place. The rotating
components of the Mixer could be seriously damaged.
6.2
SWITCHING ON THE APPLIANCE
ATTENTION
Before switching on the appliance, censure that the Mixer is connected to the electr
ic
feeding net (consult the Chapter “ELECTRIC CONNECTION” of this manual).
To switch on the appliance, follow hereunder instructions:
1. Put the Main Switch (B13 / C13) on the “I” position.
ATTENTION
Reminder valid for Mixer E094 only:
Before switching on the appliance, verify that the selector (E4) is on the middle position
of “STOP”. (See enclosure E for further details).
ATTENTION
Never start the beater rotation if the bowl isn’t at its place. The rotating
components of the Mixer could be seriously da
maged.
6.3
TOOLING UP
We describe here under a “standard procedure” which allows even to an operator without a wide
experience to carry out a procedure correctly:
BEATER POSITIONING
The automatic mortar mixer is furnished complete of tang for the beater attack. In order to place correctly
the beater proceed in the following way:
1. If this was not already opened, open the safety door (B16) and remove the bowl if it’s in the mixer
housing.
2. Unthread the tang (B12/C12) of the rotation pin (B6).
3. Fix the beater (B14/C14) to the tang (B12/C12), inserting two fins set on the beater in the special
joints present on the tang (see picture 1 of the enclosure D)
4. Screw the tang to the beater through the special screw.
5. Take the beater (B1 4/C14) and couple it with the pin (B6/C6) as shown in the picture 2.
6. Push the beater upwards till the small plug that is on the pin (B6/C6) touches its seat that is on the
beater connection (see detail 2 of picture 3).
7. At this step, turn the beater counter clockwise until the rotation stops, and then release the beater (see
detail 3 of picture 3); the spring (B8/C8) will automatically block it in the right position.
8. Fix the beater, the tang and the rotation pin through the fixing screw.
BOWL POSITIONING
Before placing the bowl (B14 / C14) inside the mixer housing, ensure to have correctly filled the same
with water and cement as foreseen by the Standards in force.
9. Open the safety door (B16) (only mixer E095).
10. Move the lever (B7 / C7) as described in the picture 4 of enclosure D.
11. Put the bowl (B14 / C14) so that it almost comes in touch with the tools housing (B11 / C11), then
move the lever (B7 / C7) according to picture 5. In this way the fixing device (B11 / C11) will block
the bowl in 3 points.
Now everything is ready for the test and you just have to close the safety door (only for mixer E095).
ATTENTION
Before starting with the standard use of the appliance, verify that all the components
have been correctly tooled up and are suitable for the test you are going to execute.
