Hydrogen Generator NM Series 2 User’s Manual
2
Introduction
Specifications
Model NMH2-100 0-100 cc/min at STP
Model NMH2-160 0-160 cc/min at STP
Model NMH2-250 0-250 cc/min at STP
Model NMH2-300 0-300 cc/min at STP
Model NMH2-500 0-500 cc/min at STP
Model NMH2-600 0-600 cc/min at STP
Hydrogen flow rate at STP.
STP: Standard temperature and
pressure:
(20°C / 1 bar absolute)
(68°F / 14.4 PSI absolute)
Model NMH2-1000 0-1000 cc/min at STP
Max outlet pressure 10.5 bar (155 psi)
Purity 99.9999%
Weight (dry) NM 100 - 160 – 250 - 300 17.5 kg
NM 500 - 600 19 kg
NM 1000 20 Kg
Power consumption
Heat Dissipation
BTU/h
Model NMH2-100 090 VA 184
Model NMH2-160 115 VA 235
Model NMH2-250 160 VA 328
Model NMH2-300 200 VA 410
Model NMH2-500 300 VA 615
Model NMH2-600 340 VA 697
Model NMH2-1000 480 VA 984
Input voltage 120 or 240V / 50-60Hz selectable
Fuse (5x20) 4A SLB @ 240VAC / 6.3A SLB @120 VAC
Pressure accuracy 0.1 bar (± 0.5 %) (1.4 PSI)
Microprocessor controlled display Graphic display, 128 x 64 pixels
Index of protection IP2x
Operating conditions:
- Temperature
- Relative humidity
15°C to 40°C ( 59°F to 104°F)
0-80%, non condensing
Storage Temperature 2°C to 60°C (35°F to 140°F)
Over voltage category II
Pollution degree 2
Sound pressure level 46 dB(A)
Case dimensions 230 x 355 x 410 mm (WxDxH)
