Matrix Telecom SETU VTEP - Setup Diagram

SETU VTEP configuration guide for Elastix Page | 3
Set Up Diagram:
(Note : PRI line from PBX is terminated to VTEP as per above setup diagram)
Host Server Environment Details
Description
Server OS
CentOS release 5.7 (Kernel 2.6.18-274.e15 on an i686)
Software Type
Elastix 2.4.0
Software version
Elastix (2.4.0)
Elastix-2.4.0-Stable-i386-bin-04Feb2013
Test Setup Equipment:
Equipment
Model
Version
SETU VTEP
N/A
V1R9
Analog Telephone
N/A
N/A
