7
3.3 CARE AND MAINTENANCE INSTRUCTION
Inspect power cords
Check E-stop cord/button
Check motor drive belt
Check running belt
Flip/replace deck
De-wax rollers
Notes/comments
Check resistance system
Lubricate pivot points
Check connecting joints
Remove covers, check
belts
Check pedal & crank
Check/lube seat
adjustment
Clean/lube guide rods
Inspect belt/cable assy.
Check locking pins
Check pulleys
Inspect upholstery
Check/tighten hardware
Lubricate Acme screw
MAKE: MODEL: S/N
LOCATION: TECHNICIAN: DATE:
Inspect power cords
Check E-stop cord/button
Check motor drive belt
Check running belt
Flip/replace deck
De-wax rollers
Notes/comments
Check resistance system
Lubricate pivot points
Check connecting joints
Remove covers, check
belts
Check pedal & crank
Check/lube seat
adjustment
Clean/lube guide rods
Inspect belt/cable assy.
Check locking pins
Check pulleys
Inspect upholstery
Check/tighten hardware
Lubricate Acme screw
In order to maximize life span, and minimize down time, all MATRIX
equipment requires regular cleaning, and maintenance items performed
on a scheduled basis. This section contains detailed instructions on how
to perform these items, the frequency of which they should be done, and a
check list to sign off each time service is completed for a specific machine.
Some basic tools and supplies will be necessary to perform these tasks
which include (but may not be limited to):
* Metric Allen wrenches
* #2 Phillips head screwdriver
* Adjustable wrench
* Torque wrench (capability to read foot lbs, and inch lbs)
* Lint free cleaning cloths
* Teflon based spray lubricant
* Mild, water soluble, detergent – such as “Simple Green”, or other Matrix
approved product
* Teflon based spray lubricant such as “Super Lube”, or other Matrix
approved product
Please find the worksheet sample for our equipment provided in this
manual and make copies as needed. Keep them up to date as the required
service / maintenance items are performed. It is critical that you also log the
accumulated (total) amount of miles or running hours on the equipment each
time service or maintenance is performed.
You may periodically see addendums to this document, as the Matrix
Technical Support Team identifies items that require specific attention,
the latest version will always be available on the Matrix website, www.
matrixfitness.com
DAILY MAINTENANCE ITEMS
1) Clean the entire machine using water and mild detergent such as
“Simple Green”, or other Matrix approved solutions (cleaning agents
should be alcohol and ammonia free).
QUARTERLY MAINTENANCE ITEMS
1) Check all connecting joint areas for tightness of bolt assemblies.
2) Ensure that there is little, or no free play at all joint assemblies once
bolts have been tightened. Installation of washer kits may be required
if free play does not come out from tightening bolts.
3) Remove plastic covers, and lubricate the ball joint where the Link Arm
and Handlebar join together. A grease gun, with a needle fitting adapter
is required for this (Matrix recommends using Superlube brand grease
with PTFE {Teflon} additive).
4) Remove plastic covers, and lubricate the Acme screw on the left and
right incline motors (Matrix recommends using Superlube brand grease
with PTFE {Teflon} additive).
MAKE: MODEL: S/N
LOCATION: TECHNICIAN: DATE:
3.4 PREVENTATIVE MAINTENANCE CHECKLIST
CHAPTER 3: PREVENTATIVE MAINTENANCE
