9.2 FASTENERS & ASSEMBLY TOOLS
QUANTITY PART # SKETCH DESCRIPTION PACKAGE COLOR
01 Z11 PURPLE
01 Z12
13 MM OPEN WRENCH PURPLE
01 Z13 6 MM ALLEN WRENCH PURPLE
04 Z01 HEX SOCKET HEAD CAP (M8 X 15L) YELLOW
02 Z14 HEX SOCKET HEAD CAP (M8 X 25L) YELLOW
08 Z02 HEX SOCKET HEAD CAP (M8 X 20L) BLACK
06 Z03 CROSS TRUSS HEAD (M5 X 10L) WHITE
04 Z04 HEX SOCKET HEAD CAP (M8 X 65L) WHITE
02 Z05 HEX SOCKET HEAD CAP (M8 X 55L) WHITE
02 Z06 FLAT WASHER (8.2 X 16.0 X 1.0T) WHITE
02 Z07 NYLON NUT (M8 X 1.25P) WHITE
04 Z08 AXLE WHITE
05 Z41 SOCKET HEAD CAP SCREW (M5 X 8L) WHITE
CHAPTER 9: ASCENT TRAINER SPECIFICATIONS AND ASSEMBLY GUIDE
