17
S
TEP 2
| SEA
T ASSEMBL
Y INS
TRUCTIO
NS & NO
TE
S
ID
DESCRIPTION
QUANITY
19
Medium Pivot Cap
6
22
M8 X 25L
SHC
6
23
Seat Link
3
24
Axle
2
25
Spring
1
ASSEMBL
Y
P
AR
T 3: SEA
T ASSEMBL
Y
T
ightento39N-m/29ft-lbs.
Rotate seat to
engage pull pin
Assemble
upper axles,
links and
pivot caps
16
18
Table of Contents
Table of Contents
2
Safety, General Care & Maintenence
3
Getting Started (Product Specifications)
5
Assembly Information
6
Markings
7
Parts List
8
Part 1 Weight Stack & User Frame Assembly
10
Part 2 Cam/Cable Assembly
12
Part 3 Seat Assembly
16
Part 4 Arm Assembly
18
Part 5 Pad Assembly
23
Part 6 Plastics Assembly
25
