12
STEP 3 | WEIGHT STACK CABLE INSTRUCTIONS & NOTES
ID DESCRIPTION QUANITY
1 M10 Nylock Nut 1
3 M10 Flat Washer 2
10 M10 X 45L SHC 1
11 Pulley 1
12 Weight Stack Cable 1
ASSEMBLY
PART 1: USER FRAME ASSEMBLY
1
3
11
12
10
Torqueto:77N-m/57ft-lbs.
