13
P
AR
T 1: USER FRAME ASSEMBL
Y
S
TEP 4
| PIV
O
T BL
OCK ASSEMBL
Y INS
TRUCTIO
NS & NO
TE
S
ID
DESCRIPTION
QUANITY
7
M10 X 30L
SHC
4
13
Pivot
Block Assembly
1
ASSEMBL
Y
14
7
Hand thread M10 bolts and leave loose
AxlesmustberedLoctited(Loctite272)andtorquedto:
180N-m/133ft-lbs.
12
14
Table of Contents
Table of Contents
2
Safety, General Care & Maintenence
3
Getting Started (Product Specifications)
5
Assembly Information
6
Markings
7
Parts List
8
Part 1 Weight Stack & User Frame Assembly
10
Part 2 Cam/Cable Assembly
12
Part 3 Seat Assembly
16
Part 4 Arm Assembly
18
Part 5 Pad Assembly
23
Part 6 Plastics Assembly
25
