18
ASSEMBLY
STEP 1 | TIE ROD TO SWINGARM ASSEMBLY INSTRUCTIONS & NOTES
PART 4: ARM ASSEMBLY
ID DESCRIPTION QUANITY
27 M6 X 12L SHC (Left Side Not Shown) 2
28 M6 Flat Washer (Left Side Not Shown) 2
29 Tie Rod (Left Side Not Shown) 2
29
28
27
Torqueto16N-m/142in-lbs.
