10
must be disconnected from the mains socket
in order to avoid injuries by accidental start up
of the machine.
• Disconnect the mains plug.
• Set the sawing unit to position “mitre operation”.
• Unlock the movable saw blade cover (7) (Fig. 1).
• When doing so lift the saw blade cover (7) to free
the saw blade (8).
• Push the saw blade blocker A (g. 7.1) until the
saw blade locks in place.
• Loosening of the saw blade xing screw with the
provided socket wrench (B) (Warning: left-hand
thread).
• Remove screw and saw blade ange.
• Remove the saw blade carefully. Warning:
Danger of injuries from the saw blade.
• Set the new saw blade on the inner saw blade
ange observing the correct size and rotational
direction of the saw blade.
• Attach the outer saw blade ange and tighten
die screw rmly.
• Set the saw blade cover back to the correct
position.
Technical data
ø blade: ø 10"
ø bore: ø 5/8"
Weight: 13,84 kg
Mitre stops left and right: 0°, 15°, 22,5°, 30°, 45°
Pivoting range: 45°/0°/45°
Inclination range: 0°–45°
Cross cut at 90°: 310 x 78 mm
Mitre cut at 45° : 210 x 78 mm
Becel cut at 45°: 310 x 42 mm
Compound cut at 45°: 210 x 42 mm
Motor V/Hz: 120 V~/60 Hz
Consumption power P1: 15 A
No load speed: 4800 /min
Maintenance
WARNING: For your own safety, turn the switch
o and remove the plug from the power source
outlet before maintaining or lubricating your
mitre saw.
General Maintenance
Occasionally use a cloth to wipe o chips and
dust from the machine. Oil the rotary parts once
a month to extend the tool life. Do not oil the
motor.
Brush Inspection
Check the motor brushes after the rst 50 hours
of use for a new machine or after a new set of
brushes have been installed. After the rst check,
examine them every 10 hours of use. When
the carbon is worn to 6 mm in length or if the
spring or shunt wire is burned or damaged,
replace both brushes. If the brushes are found
serviceable after removing, reinstall them.
Environmental Protection
End of life electrical equipment must not be
placed in household waste. Please take it to a
return point. Find out about your
nearest return point from your council or sales
outlet.
