Step 3
Frame Detail
Item
J11
J12
Z04
Z05
J14
T04
AT1
Description
Chest Pad
Seat Pad
Screw (M10x35L)
Screw (M10x30L)
Fixing Base
Back Cover
Seat Chair Screw (Cr)
Qty
1
1
3
4
1
1
1
AT1
J12
Z04x3
T04
J11
J14
Z05x4
Step 4
Frame Detail
Item
D22
D23
D24
D26
M01
M02
M16
Z14
Z12
Description
Flat Washer (Ø12)
Lock Washer (Ø12)
Screw (M12x25L)
Hanging Rod
Connect Tube;outer
Connect Tube;inner
Fix Block
Stopper Pin (Ø8)
Spring Pin (Ø4)
Qty
4
4
4
2
2
2
2
1
1
D22
D23
D24
M02
M16
M01
D26
D22
D23
D24
D22
D23
D24
M01
M02
M16
D26
D22
D23
D24
Z12
Z14
MX15_MAGNUM_OM_MG-PL34 seated row_r1_5.indd 3 4/20/15 10:21 AM
