4
ENGLISH
Z05x2
Z05x2
Z10x2
Z10x2
Z07
Z07
Z09
Z09
Z06x6
Z07x6
Z06x6
Z07x6
ASSEMBLY
1
Hardware Qty
Z06
Z07
Bolt (M10x20L)
Arc Washer (M10)
12
12
2
Hardware Qty
Z10
Z05
Z09
Z07
Flat Washer (M10)
Bolt (M10x30L)
Screw (M10x100L)
Arc Washer (M10)
4
4
2
2
NOTE: Four rubber shims are included in
case the unit is not stable.
ASSEMBLY COMPLETE
