15
A
A
A
B
C
ABLAGEBEREICH AREA
FREIER BEREICH
0,6 m
ZUSÄtZLiChe
fLÄChe
2.32 m
0.63 m
MG-A528
1 2 3
Hardware für Schritt 1
Beschreibung Menge
A Schraube (M10x25L) 6
Hardware für Schritt 2
Beschreibung Menge
A Schraube (M10x25L) 6
Hardware für Schritt 3
Beschreibung Menge
A
B
C
Schraube (M10x25L)
Flat Washer (M10)
Nut (M10)
16
16
16
DEUTSCH
Wiederholen
Sie dies für
jede Ebene
