Page #22 background imageLoading...
Page #22 background image
22
A
A
A
B
C
MG-A526
OPBERGVAK
VRIJE RUIMTE
0,6 m (2 ft)
breed pad
1,86 m
(73,36ʺ)
0,63 m
(24,6ʺ)
1
Hardware stap 1
Omschrijving Aantal
A Bout (M10x25L) 6
Hardware stap 1
Omschrijving Aantal
A Bout (M10x25L) 6
2
Hardware stap 1
Omschrijving Aantal
A
B
C
Bout (M10x25L)
Platte ring (M10)
Moer (M10)
16
16
16
3
Herhaal voor
elke laag
NEDERLANDS
