STORAGE AREA
FREE AREA
0.6 m (2 ft)
wide path
2.33 m
(91.6ʺ)
0.74 m
(28.5ʺ)
MG-A538
A
A
A
B
C
1
Step 1 Hardware
Description Qty
A Bolt (M10x25L) 6
Step 3 Hardware
Description Qty
A Bolt (M10x25L) 6
3
2
Step 2 Hardware
Description Qty
A Bolt (M10x25L) 6
Repeat for
each tier
Step 4 Hardware
Description Qty
A
B
C
Bolt (M10x25L)
Flat Washer (M10)
Nut (M10)
24
24
24
4
ENGLISH
