Matrix MG Smith User Manual

9
CHAPTER 5
：
PARTS REPLACEMENT
5.2 Lifting Mast
1. Remove the guide rods as section 5.1.
2. Disconnect the steel rope link to the mast. (Figure A)
3. Remove the whole lifting mast.
4. Remove the connect tube with fixing screw. (Figure B)
5. Remove the slipping sleeve. (Figure C)
6. Reverse step 5-1 to restore.
Figure A
Figure B

Matrix MG Smith Specifications

General

Brand	Matrix
Model	MG Smith
Category	Fitness Equipment
Language	English
