www.szmatrix.com
16
3
TXD(send)
4
NC
5
GND(land)
6
NC
7
NC
8
NC
9
NC
Safety
Do not install substitute parts on the instrument yourself, or perform any unauthorized modifications.
Please send the instrument to our company's maintenance department for maintenance to ensure that it can
be used safely.
Refer to this manual for specific warning or caution information to avoid personal injury or damage to the
instrument.
Certification and Quality Assurance
IV3600H series programmable DC power supply fully meets the technical indicators stated in the manual.
