ENGLISH
MAINTENANCE
1. Any and all part removal or replacement must be
performed by a qualified service technician.
2. DO NOT use any equipment that is damaged and or has worn or broken parts.
Use only replacement parts supplied by your country’s local MATRIX dealer.
3. MAINTAIN LABELS AND NAMEPLATES: Do not remove labels for
any reason. They contain important information. If unreadable or
missing, contact your MATRIX dealer for a replacement.
4. MAINTAIN ALL EQUIPMENT: Preventative maintenance is the key to
smooth operating equipment as well as keeping your liability to a
minimum. Equipment needs to be inspected at regular intervals.
5. Ensure that any person(s) making adjustments or performing maintenance
or repair of any kind is qualified to do so. MATRIX dealers will provide
service and maintenance training at our corporate facility upon request.
WARNING
To remove power from the unit, the power cord must
be disconnected from the wall outlet.
MAINTENANCE SCHEDULE
ACTION FREQUENCY
Unplug the unit. Clean entire machine using water and a mild soap or
other Matrix approved solution (cleaning agents should be alcohol and
ammonia free).
DAILY
Inspect the power cord. If the power cord is damaged, contact Customer
Tech Support.
DAILY
Make sure the power cord is not underneath the unit or in any other area
where it can become pinched or cut during storage or use.
DAILY
Check all connecting joint areas for tightness of bolt assemblies. QUARTERLY
Ensure that there is little, or no free play at all joint assemblies once bolts
have been tightened. Installation of washer kits may be required if free
play does not come out from tightening bolts.
QUARTERLY
Unplug the unit and remove plastic covers. Lubricate ball joint where the
Link Arm and Dual Action Handlebar join together. A grease gun, with
a needle fitting adapter is required for this (Matrix recommends using
Superlube brand grease with PTFE {Teflon} additive).
QUARTERLY
Unplug the unit and remove plastic covers. Lubricate Acme screw on
incline motor (Matrix recommends using Superlube brand grease with
PTFE {Teflon} additive).
QUARTERLY
PRODUCT SPECIFICATIONS
ASCENT ASCENT LOWER BODY
CONSOLE PREMIUM LED PREMIUM LED
Max User Weight 182 kg / 400 lbs 182 kg / 400 lbs
Product Weight 192.2 kg /423.7 lbs 195.2 kg /430.3 lbs
Shipping Weight 229 kg / 504.9 lbs 239 kg / 526.9 lbs
Overall Dimensions
(L x W x H)*
178 x 74 x 181 cm /
70.1” x 29.1” x 71.3”
178 x 74 x 181 cm /
70.1” x 29.1” x 71.3”
* Ensure a minimum clearance width of 0.6 meters (24”) for access to and passage around MATRIX equipment.
Please note, 0.91 meters (36”) is the ADA recommended clearance width for individuals in wheelchairs.
