ENGLISH
ASSEMBLY
TOOLS REQUIRED:
F Torque Wrench
F 17mm Wrench
F 6mm T-Wrench
F 8mm Allen Wrench
F 4mm Allen Wrench
F Phillips Screwdriver
PARTS INCLUDED:
F 1 Main Frame
F 2 Top Rail Covers
F 2 Pedal Arm Cover Sets
F 1 Upper Assembly
F 2 Link Arm Cover Sets
F 2 Upper/lower Dual Action Arms
F 2 Dual Action Arms Caps
F 1 Handlebar Set
F 1 Handlebar Set Cover (ALB only)
F 1 Incline Frame Cover
F 1 Top Cap Cover
F 1 Top Cap Cover Insert
F 1 Front Shroud
F 1 Console Mast Cover
F 1 Water Bottle Holder
F 1 Power Cord
F 1 Hardware Kit
Console sold separately
UNPACKING
Unpack the equipment where you will be using it. Place the carton
on a level flat surface. It is recommended that you place a protective
covering on your floor. Never open box when it is on its side.
IMPORTANT NOTES
During each assembly step, ensure that ALL nuts and
bolts are in place and partially threaded.
Several parts have been pre-lubricated to aid in assembly
and usage. Please do not wipe this o. If you have diculty,
a light application of lithium grease is recommended.
WARNING!
There are several areas during the assembly process that special
attention must be paid. It is very important to follow the assembly
instructions correctly and to make sure all parts are firmly tightened. If
the assembly instructions are not followed correctly, the equipment could
have parts that are not tightened and will seem loose and may cause
irritating noises. To prevent damage to the equipment, the assembly
instructions must be reviewed and corrective actions should be taken.
NEED HELP?
If you have questions or if there are any missing parts, contact Customer
Tech Support. Contact information is located on the information card.
