5
ENGLISH
ASSEMBLY
1
A
B
2
Hardware Qty
A
B
Socket Head Bolt
Flat Washer
4
4
C
3
Hardware Qty
C Screw (16mm) 2
D
E
F
G
4
Hardware Qty
D
E
F
G
Socket Head Bolt
Flat Washer
Hex Nut
Screw
1
2
1
5
Torque Value
70-90 Nm / 52-66 ft-lb
