Matrix planet fitness ASCENT User Manual

6
ENGLISH
L
J
I
K
A
B
ASSEMBLY
5
Hardware Qty
A
B
Socket Head Bolt
Flat Washer
4
4
6
7
Hardware Qty
H
I
J
K
L
Screw (M5-16mm)
Spring Washer
Socket Head Bolt (20mm)
Screw (M5-12mm)
Socket Head Bolt (45mm)
6
8
8
4
2
H
L
H
N
M
N
M
O
8
Hardware Qty
M
N
O
Socket Head Bolt
Spring Washer
Screw (ALB only)
4
4
2
ASCENT TRAINER
LOWER BODY ASCENT

Matrix planet fitness ASCENT Specifications

General

Brand	Matrix
Model	planet fitness ASCENT
Category	Fitness Equipment
Language	English
