Matrix planet fitness ASCENT User Manual

7
ENGLISH
ASSEMBLY
P
Note:
Be careful not to pinch any wires while
tightening screw.
9
Hardware Qty
P Screw (16mm) 1
10
Hardware Qty
P Screw (16mm) 2
P
11
Hardware Qty
Q Screw (12 mm) 2
Q
S
R
12
Hardware Qty
R
S
Bolt (20mm)
Bolt (12mm)
4
2
ASSEMBLY COMPLETE
1
2
3
4
5
6
7
LCB Communication
Extension Power Wire
TV Power
Console Connect Wires
Ethernet
Coax
Ground Wire
1
7
6
5
4
3
2
