Technical Specifications of SATATYA PARAM NVR
HARDWARE
Processor - CPU Intel® Xeon® E-2246G 3.6GHz
Memory 16GB DDR4(32/64/128 Channels), 32GB DDR4 (32/64/128/
256 Channels)
OS Drive 1 x 250 GB SSD M.2
SATA 3.0 Channels 8
Storage Capacity 144 TB (8 Hard Disks of 18 TB)
GPU Intel® UHD Graphics P630
Video Display 2x Display Ports; 1xVGA
Chassis 2U, 17" Rack Mount Server
Hot Swap HDD Bays 8x SATA 3.5" or 2.5"
RAID Intel® VRoC (Virtual RAID on CPU)
RAID Support RAID 0/1/5/10
USB 1 (F) x USB 2.0 + 4 (R) x USB 3.1
NETWORK MANAGEMENT & SECURITY
Network 4 X RJ45 (1 GbpS)
Server Management Dedicated 1 GbpS RJ45 Port
Security TPM 2.0 Support, SSL Communication
ELECTRICAL
Input Voltage 220V AC at 50/60 Hz
Power Supply System 1+1 550W Hot Swap Platinum Redundant Power Supply
MECHANICAL
Dimension (D x W x H) 660 x 430 x 88 (mm)
26” x 16.9” x 3.5”
Material SGCC
Nett Weight 13.9 kg (without Hard Disk drives)
ENVIRONMENTAL
Operating Temperature 0° to 40° C
Relative Humidity 5 - 90% RH
SOFTWARE
OS Microsoft Windows 10 IoT Enterprise 2019 LTSC
Software VMS SAMAS - upto 256 Channels, 10 User Default
VIDEO SURVEILLANCE MANAGEMENT
IP Camera Channels 32/64/128/256 IP Channels
Resolution Support 12MP, 8MP, 5MP, 3MP, 2MP, 720P, D1, CIF
Compression H.265, H.264, MJPEG
Onvif Profile Support Onvif S
IP Camera Supports Matrix Brand, Third Party - Onvif Profile S Supported
Active Directory Support Yes
