10 Matrix SIMADO GFX11 Quick Start
• LED labeled as RDY will blink (RED) fast (100 msec On—100 msec Off) when SIM Card is
absent or deactivated or SIM PIN is faulty or SIM PUK is required.
LED Indication during Normal Functioning
When the Reset Cycle is over, you can start configuring the system.
LED Activity Indication
ON
On SIMADO GFX11/GFX11E is powered on.
Off SIMADO GFX11/GFX11E is powered off.
RDY
On SIM Card is present and active.
Off
SIMADO GFX11/GFX11E is powered on but SIM Card is not
detected.
Blinking
Fast
SIM Card is absent or de-activated or SIM PIN is faulty or SIM
PUK is required.
Slow SIM Card is detected but is not registered with the network.
NW
(controlled by
Module)
Off GSM module is off.
Blinking
Fast
GSM module is on, but is not registered with the network.
(Network not available)
Slow
GSM module is on and is registered with the network.
(Network is available)
FXS
On FXS Port is Off-Hook.
Off FXS Port is On-Hook.
Blinking FXS Port is ringing.
BAT
a
a. Battery (BAT) LED indication is applicable only for SIMADO GFX11E.
On Battery is fully charged.
Off Battery is absent.
Blinking
Fast Battery is low.
Slow Battery is charging.
