23
S
TEP 2
| T
OP CAP ASSEMBL
Y INS
TRUCTIO
NS & NO
TE
S
ID
DESCRIPTIO
N
QUANTITY
42
M8 X 25L SHC
4
43
M8 Flat W
asher (2
0 mm diameter)
4
44
T
op Cap
1
43
42
44
ASSEMBL
Y
P
AR
T 8: PL
AS
TICS ASSEMBL
Y
Install the
top cap onto the w
eight stack as shown.
T
orque
to 17 N-m/147 in-lbs.
P
osition top cap so
that
the instructional placard f
aces
the user
.
22
24
Table of Contents
Table of Contents
2
Safety, General Care & Maintenence
3
Getting Started (Product Specifications)
5
Assembly Information
6
Markings
7
Parts List
8
Installation & Assembly: Value Line Part 1 Weight Stack to User Frame Assembly
10
Part 2 Weight Stack Cable Assembly
11
Part 3 Lower Right Arm Assembly
12
Part 4 Lower Left Arm Assembly
14
Part 5 User Frame Cable Assembly
16
Part 6 Upper Arm Assembly
17
Part 7 Pad Assembly
20
Part 8 Plastics Assembly
22
Part 9 Premium Kit Assembly
25
Weight Stack Frame
26
