22
STEP 1 | SHROUD ASSEMBLY ASSEMBLY INSTRUCTIONS & NOTES
PART 8: PLASTICS ASSEMBLY
ID DESCRIPTION QUANTITY
40 Front Shroud 1
41 Rear Shroud (Not shown) 1
ASSEMBLY
Install the weight stack shrouds as shown.
40
Position hangers in their lowest position
