13
STEP 2 | CAM ASSEMBLY INSTRUCTIONS & NOTES
ID DESCRIPTION QUANTITY
4 M10 Flat Washer 4
8 M10 X 20L SHC 4
ASSEMBLY
4
8
Install the hardware as shown, but DO NOT FULLY TIGHTEN .
