matson MA4INONE - Specifications

Specifications
Input voltage
200~240 Vac
Input Frequency
50 / 60 Hz
Current (Without Load)
< 0.1A
Maximum Input Current
< 15 A (under)
Maximum Efficiency in
Max. Power
> 80% (above)
Output Voltage
12V
24V
36V
48V
Maximum Amperage
30A
30A
25A
15A
Maximum Output
Charging Power
450W
900W
1000W
900W
Voltage Sensor Start-up
Position
5V
Charging Range
8 ~
14.8V
16 ~
26.4V
27 ~ 39V
40 ~ 55V
Average Charging
Voltage (Vblk)
14.5V
29.0V
42.6V
56.5V
Floating Charging
Voltage (Vflt)
13.8V
27.6V
39.9V
53.2V
Protection
Function
Short
Circuit
Protection
Yes
Reverse
Connectio
n
Protection
Yes
Overheat
Protection
Yes
Voltage / Current
Precision
< 5%
Maximum Float Charging
Time
No Limit
Operating Ambiance
Temperature
In Full Load: -20 ~ 60°C
Operating Ambiance
Humidity
Maximum 95% RV, Not Condensing
Cooling System
The fan automatically adjusts according to
the inner temperature.
Average Temperature in
Housing
< 70°C
Dimensions
300 x 223 x 101mm
Weight
4.5kg
