General Information - Safety
TI008G0001
Description of Pictograms
Pictograms have been applied on the machine to
explain following situations:
Danger
Obligation
Prohibition
Special indications (example: direction of rotation
of the fan, etc)
Many accidents are often caused by the non-
observance of the simplest safety rules or poor
knowledge of the instructions given by the manu-
facturer.
To avoid possible danger situations, some of them
are highlighted through special signs represented
by suitable standardized symbols (pictograms).
Below is the list of the most common symbols ap-
plied to our machines:
Danger pictograms
These triangular signs are framed in black with a yellow background and the symbol is black.
Warning !
The machine is with remote control
or with automatic system and may
start without notice.
Warning !
Vessel under pressure.
Warning !
Risk of high temperature surface
(> 70 °C)
Warning !
Air delivery.
Warning !
Risk of electrical shock.
Prohibition pictograms
These circular signs are framed in red, with white background and the symbol is black.
No pressure in
the receiver.
No working on
the machine.
No voltage.
