-11-
INSTALLING BATTERIES [Alkaline AA Batteries x6]
INSTALLING ADAPTER
LOADING STAPLES [up to 100 No.11-1M staples can be loaded]
* Make sure to disconnect the power cord from the outlet before installing.
Caution: Make sure to use six alkaline AA batteries. When other types of batteries or rechargeable
batteries are used, the performance of this machine could be degraded or it may not operate
correctly.
①Plug the power cord
 into the AC adapter.
②Plug the plug of the
 AC adapter into the
 body of the device.
③Plug the power cord
 into the power outlet.
①Push and slide open the cover
 underneath the machine.
②Insert the batteries, aligning
 them with the plus (+) and
 minus (-) signs on the bottom.
③Put the cover back, inserting
 its tabs into a place.
①Pull the front cover towards
 you while pushing both
 sides of the cover
 inward, then lift it up.
②Press the magazine open button,
 slide the magazine out, and load
 No.11-1M staples into the magazine.
(Up to 100 staples)
③Push the magazine in until
 it clicks.
④Lower the front cover,
 then push it in until it stops.
・When batteries and the
adapter are used together,
power from the adapter is
used in priority.
・When you do not want to
use the adapter, disconnect
the plug from the device.
While the adapter is
plugged in, power is not
supplied from the batteries.
Caution:
・No.10 or No.11-10㎜
cannot be used.
・The magazine may
come out quickly, so do
not look inside closely.
Caution:
・If the magazine is not
pushed in enough, the
device will not operate.
❶
❷
❶
❷
❶
❷
