Max G Series User Manual

8
Model #
G004 G015
G045 G105 G240
Max Flow (1) 4 LPM
(1GPM)
15 LPM
(4 GPM)
45 LPM
(11.9 GPM)
105 LPM
(28 GPM)
240 LPM
(64 GPM)
Operating
Pressure
425 bar
(6000psi)
425 bar
(6000psi)
425 bar
(6000psi)
425 bar
(6000psi)
see below
Filtration 10 micron 15 micron 20 micron 20 micron 30 micron
Max Temp (2) 160°C
(320°F)
160°C
(320°F)
160°C
(320°F)
160°C
(320°F)
160°C
(320°F)
Weight 1.2 kg 1.8 kg 3.7kg 7.7kg 21 kg
Displacement
cc/rev
1.8 4.2 13.5 38 133
Typical
K-Factor
(Pulses/cc)
500 200 70 25 7
NPT Port Size 1/8” 3/8” 1/2” 3/4”
1” to 280 bar (4000 psi)
SAE Port Size #4 #6 #8 #10
#16 to 425 bar (6000psi)
(1) For fluids above 100cps fluid, flow rate must be derated. See graphs.
(2) Standard transmitter capable to 85°C (185°F).
Flow meter Specifications

Max G Series Specifications
