1. SPECIFICATIONS AND TECHNICAL DATA
1. NAME OF PARTS (SEE Fig.1)
2. TOOL SPECIFICATIONS
3. FASTENER SPECIFICATIONS
ENGLISH
OPERATING INSTRUCTIONS MANUAL
1 Frame 7 Grip
2 Cylinder Cap 8 Exhaust Cover
3 Contact Arm 9 Pusher
4 Nose 0 Adjustment Dial
5 Magazine a Rafter Hook (SN883RH3,SN890CH3/34, SN883CH2/28)
6 Trigger b Swivel Joint (SN883RH3,SN890CH3/34, SN883CH2/28)
PRODUCT NO.
SN883RH3 SN890CH3/34 SN883CH2/28 SN890CH2<34>(CE) SN883-100CH/34(CE)
HEIGHT 11-7/8" (300 mm) 12-1/2" (316 mm) 12-1/4" (310 mm) 316 mm (12-1/2" ) 344 mm (13-1/2")
WIDTH 4-3/4" (121 mm) 4-3/4" (121 mm) 4-3/4" (121 mm) 121 mm (4-3/4") 121 mm (4-3/4")
LENGTH 20-3/4" (526 mm) 17-1/8" (435 mm) 16-7/8" (428 mm) 435 mm (17-1/8") 435 mm (17-1/8")
WEIGHT 7.9 lbs. (3.6 kg) 8.0 lbs. (3.6 kg) 7.8 lbs. (3.5 kg) 3.3 kg (7.28 lbs.) 3.4 kg (7.51 lbs.)
LOADING CAPACITY 64 Nails 90 Nails
RECOMMENDED
OPERATING PRESSURE
70 to 100 p.s.i.
(5 to 7 bar)
5 to 7 bar
(70 to 100 p.s.i.)
AIR CONSUMPTION
0.077 ft3 at 90 p.s.i. operating pressure
(2.18L at 6 bar operating pressure)
2.18L at 6 bar 90 p.s.i.
operating pressure
2.4L at 6 bar 90 p.s.i.
operating pressure
PRODUCT NO.
SN883RH3 SN890CH3/34 SN883CH2/28 SN890CH2<34>(CE) SN883-100CH/34(CE)
NAIL LENGTH
2" to 3-1/4"
(50 to 83 mm)
2" to 3-1/2"
(50 to 90 mm)
2" to 3-1/4"
(50 to 83 mm)
50 to 90 mm
(2" to 3-1/2")
65 to 100 mm
(2-1/2" to 4")
SHANK DIAMETER
.113" to .148"
(2.9 to 3.8 mm)
.113" to .131"
(2.9 to 3.3 mm)
2.8 to 3.3 mm
(0.110" to .131")
SHANK TYPE Smooth, Ring, Screw
HEAD DIAMETER
.267" to .295"
(6.8 to 7.5 mm)
.256" to .303"
(6.5 to 7.7 mm)
6.5 to 7.7 mm
(0.256" to .303")
COLLATION ANGLE 21 degree 34 degree 28 degree 34 degree
HEAD Full round head Offset/Clipped head
