10. Wiring Diagrams
ENC2 SW1
SWITCH
FOR NETWORK ADDRESS
SETTING
MODEL
DIP SW1
“0~F” of the ENC2 and “ON/OFF” of the SW1 mean the addresses of
the different units, respectively.
FP-42.5BM
ON
1 2 3 4
NOTE:
The functions in the dashed rectangle are available for particular
air-conditioner.
FP-51BM
ON
1 2 3 4
FP-68BM
ON
1 2 3 4
FP-85BM
ON
1 2 3 4
FP-102BM
ON
1 2 3 4
MAXA DC Fan Coil Unit
