Maxcom MM29D 3G User Manual

17
6.6 Mount/Unmount the Unit Base Lifter
6.6.1 Mounting the Unit Base Lifter
In oder to mount the unit base lifter, switch off the phone and put it on
its keypad. Insert two pins into openings 1 and 2 located at the top part
of the phone. Then, fold back the lifter to insert pins into openings 3
and 4 until a click is heard.
6.6.2 Unmounting the Unit Base Lifter
To unmount the unit base lifter, switch off the phone and place it with
its keypad facing downwards. Hold the sides of the phone, use your
thumbs to gently press two pins, and gently lift the lifter. After two first
pins are released, remove the lifter.
6.7 Mounting the Phone on the Wall
The telephone has special hooks for wall mount. The hooks are located
where a unit base lifter should be installed. If you want to wall mount
the phone, do not install the unit base lifter.
1. Pull out the handset hook, and place it back the other way
around so that it will hold the handset in vertical position.
1
3
2
4
CLICK

Maxcom MM29D 3G Specifications

General

Type	DECT telephone
Product color	Black
Display diagonal	2.8 \
Display resolution	128 x 64 pixels
Compatible memory cards	Not supported
WAP	Yes
Data network	-
3G bands supported	900, 1800 MHz
SIM card capability	Single SIM
2G bands (primary SIM)	900, 2100 MHz
Mobile network generation	3G
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Talk time (2G)	2 h
Battery capacity	600 mAh
Standby time (2G)	120 h
Subscription type	No subscription
Phonebook capacity	600 entries

Weight and Dimensions

Depth	206 mm
Width	164 mm
Height	100 mm
Weight	624 g
