03-ConnectingMIDkWh-meter
Maxemcanmeasuredierentelementsthroughan externalMIDcertiedkWh-meter.In
orderfortheautocongurationtofunctionproperly,thekWh-metermustbesettotheright
address.Thisisdoneasfollows:
Node/device Address
Solar #1 001
Solar #2 011
Charging station #1 002
Charging station #2 012
Heat pump #1 004
Heat pump #2 014
Locationofthe‘addressing’functioninthemenu
SET
OK
1 2 3
Addressing multiple elements
Numberofdevices
Devicetype
Standard addressing kWh-meter
Node/device Address
Gridconnection 100
Solar 001
Charging station 002
Heat pump 004
Addressing
ConguringanMIDkWh-meter
Holdthebuttonfor2sec.toenterthemenu,ortogoupinthemenu.
Scrolldownthroughmenuoradjustsettingvalue.
Presstogetintoamenuitemoracceptanadjustment.
Presstoadjustasetting.
NavigationthroughthemenuoftheABBB23/B24kWh-meter
If you see this icon in the display of the kWh-meter, there is an active
dataconnectionwithMaxem.
