13
13 Adjust Recline
To rotate seat forward or backward,
lift the recline/fold lever and rotate
seat (Figure 13).
To let seat back drop down, detach
the seat recline clip located on the
upper half of the seat back (Figure
13a).
7
To Use
14 Fold Stroller
NOTE: Seat can remain on frame when folding stroller.
Close canopy.
Press the button while lifting up on seat recline/fold lever and fold seat forward (Figure 14).
Pull up on both handlebar releases and fold handlebar forward (Figure 14a).
4
Pull up on frame fold handle and lift upward to fold stroller (Figure 14b)
5
Latch the frame lock. Stroller will stand when folded (Figure 14c). Note: Stroller can also be folded without the seat
(Steps 14a-14b).
14a 14b14
14c
13a
Detach
