MAXIMATOR DLE 5 - Page 19

19
Withdraw the air cylinder from the top cover
and the air piston.
Pull the air piston slightly out of the top cover and remove the retaining pin and bolts.
Pull the piston rod out of the top cover into
the direction of the HP part.
Remove the O ring from the air piston.
