MAXIMATOR DLE 5 - Page 20

20
8.2.1.2 Dismantling of top cover and bottom cover
Remove the locking ring.
Knock the bearing bush out of the top and bottom covers by means of a plastic mandrel.
Remove the O rings from the bearing bush.
Remove the sliding rings and O rings from the bearing bush.
