No. Description
1 ON/OFF trigger switch handle
2 Laser vertical adjustment knob
3 Laser horizontal adjustment knob
4 Lower blade guard
5
Base
6
Mitre handle
7
Positive stop locking lever
8
Bevel locking handle
No. Description
9 Mitre detent override
10 Table
11 Stop plate
12 Left extension wing
13
Sliding fence
14
Hold-down clamp
15
Power cord storage
16
Built-in carry handle
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
KNOW YOUR SLIDING MITRE SAW
