7
SPECIFICATIONS
MOTOR
POWER SOURCE 120V AC, 60 Hz, 15A
SPEED 3200 RPM (No load)
BRAKE ELECTRIC
DOUBLE INSULATED Yes
ARBOUR SHAFT SIZE 5/8" (15.9 mm)
BLADE
DIAMETER 10" (25.4 cm), 60-tooth carbide-tipped
ARBOUR SIZE 5/8" (15.9 mm)
ROTATING TABLE
MITRE ANGLE RANGE 0°–50° Right & Left
POSITIVE MITRE STOPS 0°, 15°, 22.5°, 31.6°, 45° Right & Left
BEVEL ANGLE RANGE 0°–45° Right / 0°–47° Left
BEVEL POSITIVE STOPS 0°, 33.9°, 45° Right & Left
CUTTING CAPACITY
CROSSCUT (MAXIMUM HEIGHT) 3 1/2" x 11 1/2" (8.9 x 29.2 cm)
CROSSCUT (MAXIMUM WIDTH) 3 1/2" x 12 1/2" (8.9 x 31.8 cm)
MITRE 45° RIGHT & LEFT 3 1/2" x 8 3/4" (8.9 x 22.2 cm)
BEVEL 45° RIGHT 1" x 12 1/2" (2.5 x 31.8 cm)
BEVEL 45° LEFT 1 5/8" x 12 1/2" (4.1 x 31.8 cm)
45° MITRE AND 45° BEVEL 1 5/8" x 8 3/4" (4.1 x 22.2 cm)
CROWN MOULDING NESTED 5 3/4" (14.6 cm)
BASE MOULDING AGAINST FENCE 3 1/2" (8.9 cm)
NET WEIGHT 20.06 kg (44 lb 4 oz)
LASER
CLASS IIIA
LASER WAVELENGTH 630–660 nm
MAX. LASER OUTPUT < 5 mW
SPECIFICATIONS
