REPLACEMENT PARTS
WARNING!
• Any attempt to repair or replace electrical parts on this mitre saw
may create a hazard unless the repairs are carried out by a qualified
service technician.
MAXIMUM™ 10" DUAL-BEVEL SLIDING MITRE SAW
When servicing the Mazimum™ 10" Dual-Bevel Sliding Mitre Saw, use only Maximum™
replacement parts. The use of any other parts may cause damage to the product. All
servicing should be performed by a qualified service technician. To find the nearest
technician, call the toll-free helpline, at 1-888-670-6628.
I.D.No. Description Size Q'ty I.D. No. Description Size Q'ty
082J CUSHION 2 2JTR INSULATING SLEEVE 1
082L BOLT 2 2M0S LIMIT SWITCH 1
082P SCREW STOP 1 2MC3 ROLL PIN 2
082Q LOCK NUT 1 2MRE BLADE 1
083Z CORD CLAMP 1 2N7W BRACING PLATE 1
0CES COMPRESSION SPRING 1 2NAH CR. RE. TRUSS HD. SCREW M4*0.7-8 1
0CPD CENTRE BOLT 1 2RXR CR. RE. PAN HD. SCREW M4*0.7-8 2
0DT4 ROLLING WHEEL 2 2S5C CAUTION LABEL 1
0DT7 BEARING 2 2S5D WARNING LABEL 1
0DTZ ARBOUR COLLAR 2 2VEP SHAFT 1
0DVJ BLADE WRENCH 1 2VH6 LINEAR MOTION BEARING 2
0J3Q HEX WRENCH 5 MM 1 2VN7 BLANKET WASHER φ25*φ38 4
0J6P FLAT WASHER φ6*16-2 1 2VS0 LEAD WIRE ASS'Y 1
0JAZ WAVE WASHER WW-6 1 2VZ1 RUBBER INSERT 8
0JB0 WAVE WASHER WW-8 4 2WK0 COMPRESSION SPRING 1
0JBG DISC SPRING WASHER φ12 1 306G BUSHING 1
0JC8 SPRING PIN 1 31XE SLIDE PLATE 3
0JCT SPRING PIN 2 32R9 CHUCK NUT M5*0.8 T=5 1
0JE7 C-RING 1 32RA CHUCK NUT M6*1.0 T=6 4
0JMN O-RING 1 32RB CHUCK NUT M8*1.25 T=8 1
0JMP O-RING 1 32RC CHUCK NUT M12*1.75 T=12 1
0JNR O-RING ROD 2 34BN COMPRESSION SPRING 1
0K05 HEX. SOC. TRUSS HD. SCREW M8*1.25-20 4 34NJ UPPER TUBE 2
0K9Y DRIVE SCREW φ2.3-5 5 34NK UPPER TUBE 2
0KR2 LOCK NUT M5*0.8 T=5 2 351P BUMPER 1
0KR3 LOCK NUT M6*1.0 T=6 1 35QJ LEVER 1
0KTP CABLE CLAMP 1 37TB FLAT WASHER φ6*13-1 2
0KUW TERMINAL 4 37TC FLAT WASHER φ8*16-2.5 1
0S1S COLLAR 1 38AW SPRING GUARD 1
20PL CLAMP HANDLE 2 3ADS HEX. NUT M6*1.0 T=5 2
224U ROLL PIN 2 3ADZ CHUCK NUT M10*1.5 T=10 1
22A4 LOCKING CABLE TIE 1 3AE3 FLAT WASHER φ10*20-3 1
23NX CORD GUARD M2505 1
3BKA EXTENSION WING (RIGHT) 1
25B1 CR. RE. TRUSS HD. SCREW M5*0.8-25 1
3BKB EXTENSION WING (LEFT) 1
27PQ ROLL PIN 1
3BKD SLIDE-BAR SEAT (FRONT) 1
2BQA PLATE 2
3BPY CLAMP HANDLE 1
2C0F CONTROLLER ASS'Y 1
3BSB TABLE BRACKET 1
2D7E COMPRESSION SPRING 1
3DJ8 LOCATING BAR 1
2E35 TRIGGER 1
3DJ9 FRAME ENDCAP 1
2F39 CLEVIS PIN 1
3DJA WASHER BEARING 1
PARTS LIST (A) FOR MITRE SAW
