Maximum 055-6767-0 - Page 61

61
REPLACEMENT PARTS
I.D. No. Description Size Q'ty I.D. No. Description Size Q'ty
3DJG SPACER 2 3HHX CR. RE. PAN HD. TAPPING SCREW M4*18-16 2
3DJL SET PLATE 1 3HJ0 CR. RE. PAN HD. TAPPING SCREW M3*24-8 1
3DJP MITRE BAR ASS’Y 1 3HJ5 CR. RE. PAN HD. SCREW M5*0.8-6 3
3DJR MITRE BAR 1 3HJA CR. RE. PAN HD. SCREW M5*0.8-25 1
3DK9 BOLT 1 3HJE HEX. SOC. SET SCREW M6*1.0-16 1
3DKA BOLT 1 3HJF HEX. SOC. SET SCREW M6*1.0-16 2
3DKC SEGMENT HANDLE 1 3HJG HEX. SOC. SET SCREW M6*1.0-10 2
3DKF PIVOT SHAFT 1 3HJH HEX. SOC. HD.CAP SCREW M5*0.8-40 3
3DKJ TORSION SPRING 1 3HJK HEX. SOC. HD.CAP SCREW M6*1.0-12 2
3DLH FOLLOWER PLATE (RIGHT) 1 3HJL HEX. SOC. HD.CAP SCREW M5*0.8-10 3
3DLJ FOLLOWER PLATE (LEFT) 1 3HJP
HEX. SOC. TRUSS HEAD & WASHER ASS’Y M6*1.0-16 2
3DMM BEARING COVER 3 3HJU HEX WASHER HD BOLT M8*1.25-20 1
3DTM SHAFT SLEEVE 1 3HJV HEX. HD. BOLT M6*1.0-25 2
3DTZ RUBBER PAD 1 3HJW HEX. NUT M5*0.8 T=4 1
3DWQ PLATE 1 3HJX SELF-LOCKING RING 2
3DWT INSERT 1 3HJY LOCK NUT M6*1.0 T=9 2
3DWV PIN 2 3HJZ FLAT WASHER φ4*8-1 2
3DWW LASER SET 1 3HK1 FLAT WASHER φ12*21-1 1
3DWY PIVOT SUPPORT 1 3HK2 FLAT WASHER φ5*14-1 2
3DWZ LASER PLUNGER HOUSING 1 3HK3 FLAT WASHER φ6*12-1 2
3DXM LINEAR MOTION BEARING 1 3HK4 FLAT WASHER φ4*10-1 1
3F4X SHAFT 1 3HK6 FLAT WASHER φ6*10-1 3
3F8Q PLUNGER HOUSING 1 3HK8 FLAT WASHER 1/4*1/2-3/32 1
3FJG CUTTER SHAFT GUARD 1 3HK9 FLAT WASHER 3/8*29/32-1/8 1
3FJH SET PLATE 1 3HKB HEX. SOC. SET SCREW M6*1.0-12 1
3FJN FENCE 1 3J5W NEEDLE POINTER 1
3FJP ASSIST-FENCE (RIGHT) 1 3JCP INSTRUCTION MANUAL 1
3FJQ WRENCH SET 1 3JDM NEEDLE POINTER 1
3FJS MOTOR HANDLE (UP) 1 3JE7 HEX. SOC. HD. CAP SCREW M5*0.8-20 1
3FJT MOTOR HANDLE (DOWN) 1 3JQE PLATE (RIGHT) 1
3FJU CABLE SHIELD 1 3JQF PLATE (LEFT) 1
3FJV ASSIST FENCE (LEFT) 1 3JST LABEL 1
3FM3 SPECIAL BOLT 2 3JSU CAUTION LABEL 1
3FS5 BASE 1 3JSV TILTING SCALE 1
3FVK LASER COVER 1 3JSW CAUTION LABEL 1
3FVL COVERLASER COVER 1 3JSX CAUTION LABEL 1
3G0D HEX. SOC. HD.CAP SCREW M6*1.0-16 1 3JSY CAUTION LABEL 1
3G0U CLAMP BOLT 1 3JSZ CAUTION LABEL 1
3G0W CLAMP BOLT 1 3JT0 WARNING LABEL 1
3G10 KNOB-HANDLE 1 3JT1 WARNING LABEL 1
3G14 PLUNGER HANDLE 1 3JT2 DUST BAG ASS’Y 1
3G3T PLUNGER HANDLE 1 3K0U ANCHOR PLATE 1
3G3V CLAMP HANDLE 2 3KJ1 INSULATING SLEEVE 1
3GGC COMPRESSION SPRING 1 3KRJ SOC. TRUSS HEAD ROUND NECK SCREW M6*1.0-10 1
3GGE TABLE INSERT 2 3KRL SOC. TRUSS HEAD ROUND NECK SCREW M6*1.0-14 1
3GGF TILTING SCALE 1 3KRN SOC. TRUSS HEAD ROUND NECK SCREW M6*1.0-16 1
3GGG LOCKING HANDLE 1 3KTN SOC. ROUND WASHER HEAD SCREW M5*0.8-16 2
3GGH SPECIAL BOLT 1 3KTP SOC. PAN HEAD SCREW M5*08-20 1
3GGL LOCKING ROD 1 3KTQ SOC. TRUSS HEAD SCREW M6*1.0-8 1
3GGP ARM-MITRE 1 3KTR SOC. COUNTERSUNK HEAD TAPPING SCREW M4*18-16 1
3GGQ ARM MITRE COVER 1 3KTT SOC. COUNTERSUNK HEAD TAPPING SCREW M4*18-25 1
3GGS POWER CORD CLAMP 1 3KTU SOC. COUNTERSUNK HEAD TAPPING SCREW M4*16-20 4
3GGT CLAMP-CORD 1 3KTV SOC. BUTTON HEAD CAP SCREW M5*0.8-16 1
3GH0 PC-GUARD 1 3KTW SOC. TRUSS HEAD SCREW M4*0.7-10 6
3GPZ ROCKER SWITCH 1 3KTX SOC. BUTTON HEAD CAP SCREW M5*0.8-6 3
3H25 LEVER BRACKET 1 3KTZ SOC. FLAT HEAD SCREW M4*0.7-8 4
3H26 LEVER 1 3KUA SOC. PAN HEAD SCREW M5*0.8-55 2
3H38 BUTTON SWITCH 1 3KU1 SOC. FLAT HEAD SCREW M6*1.0-22 1
3H3E TORSION SPRING
1 3KU2 SOC. PAN HEAD SCREW M6*1.0-16 4
3H3G TABLE 1 3KU4 SOC. PAN HEAD SCREW M5*0.8-8 3
3H46 MOTOR ASS'Y 1 3KU5 SOC. PAN HEAD SCREW M4*0.7-8 1
3H9P POWER CABLE 1 3KU5 SOC. PAN HEAD SCREW M4*0.7-8 1
3H9T LEAD WIRE ASS'Y 1 3KU6 SOC. PAN HEAD SCREW M4*0.7-12 1
3H9U LEAD WIRE ASS’Y 1 3KU7 SOC. PAN HEAD SCREW M5*0.8-35 1
3HA0 BUTTON 2 3KU8 SOC. PAN HEAD SCREW M5*0.8-12 3
3HAA KNOB 1 3KU9 SOC. PAN HEAD SCREW M5*0.8-16 3
3HHN CR. RE. COUNT HD. SCREW M5*0.8-12 4 3KUB SOC. PAN HEAD ROUND NECK SCREW M6*1.0-12 1
3HHQ CR. RE. COUNT HD. SCREW M3*0.5-6 2 3N4Y HOLD-DOWN CLAMP ASS’Y 1
3HHR
CR. RE. TRUSS HD. ROUND NECK SCREW M5*0.8-12 1
PARTS LIST (B) FOR MITRE SAW
MAXIMUM™ 10" DUAL-BEVEL SLIDING MITRE SAW
