Maxitrol Mertik GV60 - Turning the Appliance On; Turning the Appliance Off; Flame Height Adjustment

15 / 20
© 2019 Mertik Maxitrol GmbH & Co. KG, All Rights Reserved.
ENGLISH
TO TURN OFF APPLIANCE
Handset
▪ Press OFF button.
Wall Switch / Touchpad / Switch Panel
▪ Press button “B” (see gure 25).
FLAME HEIGHT ADJUSTMENT
Handset
▪ In standby mode: Press and hold (large
ame) button to increase ame height.
▪ Press and hold (small ame) button to de-
crease ame height or to set appliance at
pilot ame.
▪ For ne adjustment tap the
(large ame)
or
(small ame) buttons.
Wall Switch/Touchpad/Switch Panel (see gure 25)
▪ Press and hold button “A” to increase ame height.
▪ Press and hold button “C” to decrease ame height or to
set appliance at pilot ame.
▪ For ne adjustment tap button “A” or “C”.
Designated Low Fire and High Fire
MAN
C
▪ Double-click (small ame) button. “LO”
will be displayed.
NOTE: Flame goes to high re rst before
going to designated low re.
MAN
C
▪ Double-click (large ame) button. Flame
automatically goes to high re. “HI” will be
displayed.
If the appliance will not operate, follow the instructions
“TURN OFF GAS TO APPLIANCE” (page 19).
TO TURN ON APPLIANCE
When pilot ignition is conrmed, motor turns automatically
to maximum ame height.
▪ Turn MANUAL knob on valve to the ON, full counter-clock-
wise
position (see gure 27, page 19).
▪ Place ON/OFF switch (if equipped) in I (ON position).
Handset
▪ Simultaneously press the OFF and (large
ame) buttons until a short beep conrms
the start sequence has begun; release but-
tons.
▪ Continuing beeps conrm the ignition is in
process.
▪ Once pilot ignition is conrmed, there is
main gas ow.
▪ After main burner ignition the handset will
automatically go into manual mode (CSA
version, CE version).
Wall Switch / Touchpad / Switch Panel
▪ Press button “B” (see gure 25) until a short beep conrms
the start sequence has begun; release button.
▪ Continuing beeps conrm the ignition is in process.
▪ Once pilot ignition is conrmed, there is main gas ow.
If the pilot does not stay lit after several tries, turn the main
valve knob to OFF and follow the instructions “TURN OFF
GAS TO APPLIANCE” (page 19).
STANDBY MODE (Pilot Flame)
Handset
▪
Press and hold (small ame) to set appliance at pilot ame.
Wall Switch / Touchpad / Switch Panel
▪ Press and hold button “C” (see gure 25) to set appliance
at pilot ame.
Figure 25: Switch Panel and Wall Switch/Touchpad
A) Increase ame height
B) ON/OFF
C) Decrease ame height
