MaxJax M7K - Specifications

MaxJax™ Portable Mid-Rise Lift 8 P/N 5900268 — Rev. A4 — July 2022
Specifications
Model M7K
Lifting capacity 7,000 lbs. / 3,175 kg
Maximum capacity front axle 3,500 lbs. / 1,587 kg
Maximum capacity rear axle 3,500 lbs. / 1,587 kg
Max Load per Arm 1,750 lbs. / 794 kg
A Overall Height
(Hydraulic Cylinders at full height)
89.5" / 2,273 mm
B Column Height
64" / 1,629 mm
C Typical Width (edge of Base Plates)
105" – 135" / 2,667 mm – 3,429 mm
D Arm Reach (min)
26" / 658 mm
E Arm Reach (max)
40" / 1,016 mm
F Minimum Pad Height
5.25" / 137 mm
G Maximum Lifting Height (with Adapter)
50" / 1,270 mm
Maximum Lifting Height (with Pad) 47.25" / 1,204 mm
Safety Locks 7
Post Weight 300 lbs. / 136 kg
Raising/Lowering Time*
45 seconds
Motor**
110/220 VAC, 50/60 Hz, 1 Ph
* Lowering is much slower with no Vehicle on the Lift.
** Must specify at time of purchase.
Specifications subject to change without notice.
