maxon motor EC Series User Manual

maxon EC motor
2 Document ID:: rel8710 EC-i30 IE
Edition: March 2019 Operating Manual
© 2019 maxon motor. Subject to change without prior notice.
Safety Guidelines
Qualified
personnel
Do not engage with any work unless you possess the necessary skills.
Legal
requirements
Observe any regulation applicable in the country and/or at the site of implementation with regard to
health and safety/accident prevention and/or environmental protection.
Make sure that all associated devices and components are installed according to local regulations.
Additional safety
equipment
Be aware that, by principle, an electronic apparatus can not be considered fail-safe. Therefore, you must
make sure that any machine/apparatus has been fitted with independent monitoring and safety equip-
ment. If the machine/apparatus should break down, if it is operated incorrectly, if the control unit breaks
down or if the cables break or get disconnected, etc., the complete drive system must return – and be
kept – in a safe operating mode.
Repairs Be aware that you are not entitled to perform any repair on components supplied by maxon motor.
Danger to life Touching live wires causes death or serious injuries!
• Consider any power cable as connected to live power, unless having proven the opposite!
• Make sure that neither end of cable is connected to live power!
• Make sure that power source cannot be engaged while work is in process!
• Obey lock-out/tag-out procedures!
• Make sure to securely lock any power engaging equipment against unintentional engagement
and tag it with your name!
Max. supply
voltage
The connected supply voltage must be between 8 VDC and 28 VDC. Permanently applied voltages
above 30 VDC will destroy the unit.
Electrostatic sen-
sitive components
The built-in electronics can be destroyed by externally applied electronic discharges during transport,
installation, and during operation.
• Make sure to wear working cloth in compliance with ESD.
• Handle the device with extra care.
• Limit the voltage between flange and any live parts to 500 VDC
Temperature During operation, the temperature of housing, flange, or other components may exceed 60°C.
READ THIS FIRST
These instructions are intended for qualified technical personnel.
Prior commencing with any activities…
• you must carefully read and understand this manual and
• you must follow the instructions given therein.
The EC-i30 with integrated electronics is considered as partly completed machinery according to EU Directive 2006/42/
EC, Article 2, Clause (g) and is intended to be incorporated into or assembled with other machinery or other partly
completed machinery or equipment.
Therefore, you must not put the device into service,…
• unless you have made completely sure that the other machinery – the surrounding system the device is intended to
be incorporated to – fully complies with the requirements stated in the EU directive 2006/42/EC!
• unless the surrounding system fulfills all relevant health and safety aspects!
• unless all respective interfaces have been established and fulfill the stated requirements!

maxon motor EC Series Specifications

General

Series	EC
Motor Type	Brushless DC
Voltage	12V, 24V, 48V
Nominal Speed	Varies by model (e.g., 3000 - 10000 rpm)
Nominal Torque	Varies by model (e.g., mNm range)
Peak Torque	Varies by model (typically higher than nominal torque)
Efficiency	Up to 90%
Weight	Varies by model
Protection Class	IP54
